2.2.6 Commissioning the CP system on the PROFIBUS-DP
Please note
Please observe also the switching-on instructions in the
manual for your controller.
Proceed as follows:
1. Connect the field bus cable to the field bus node.
2. Switch on the operating voltage:
S for all field bus slaves,
S for the CP system.
3. Switch on the operating voltage for the master module.
Configuration run Some master systems carry out a comparison between the
NOMINAL and the ACTUAL configurations automatically
when the system is switched on. For this configuration run it
is important that:
– the specifications for the NOMINAL configuration are com-
plete and correct (see also section 2.1.2).
– thepowersupplyfortheprogrammablelogiccontroller
and that for the field bus slaves is switched on either sim-
ultaneously or in the sequence indicated above.
