2. Commissioning
2-25
Festo Festo P .BE CP FB13-E-EN en 9910c
2.2.5 STEP 7 V4.x / 5.0 – Hardware configurator
Preparations
CD ROM 1. Copy the device data base (GSD) of the valve terminals
into the directory \STEP7\S7DATA\GSD on your pro-
grammer/PC. The device data base can be found on the
accompanying CD ROM.
File: VI10FB13C.GSD
The device data base can either be
S copied manually into the abo ve mentioned directory
(e.g. with Windows Explorer) or
S loaded via menu item “Extras”“Install new GSD” in
the mask “Hardware config.”.
Please note
Update the hardware catalogue, if you copy the device
data base during work with STEP 7. Menu in Hardware
Config: “Extras” - “Update catalogue”.
