Festo CP-FB13-E - Bus Parameter;Reaction Times; Transmission Times on the PROFIBUS-DP

2. Commissioning
2-44
Festo Festo P .BE CP FB13-E-EN en 9910c
2.3.7 Bus parameter/reaction times
Baud rate
(kBaud)
max T
SDR
(T
Bit
) max T
SDR
(T
Bit
)
...187,5 60
500 100
1500 150
11
3000 250
1
1
6000 450
12000 800
2.3.8 Transmission times on the PROFIBUS-DP
Please note
S ObserveherethecycletimeofyourPLCandtheupdate
time of the PROFIBUS-DP.
The time delay within the CP system depends on the amount
of data and on the string assignment. It amounts to:
< 5ms.
Please refer to the manual for your controller for the method
of ascertaining the total time required for transmission.
