Festo CP-FB13-E - Configuration with a Siemens Master

2. Commissioning
2-13
Festo Festo P .BE CP FB13-E-EN en 9910c
2.2 Configuration with a Siemens master
Please note
Various configuration programs are available for use in
conjunction with a Siemens master . Please observe the
relevant procedure with your configuration program.
The following chapters describe as an example the most im-
portant steps required for configuring the Festo valve ter-
minal with the C OM PROFIBUS software or with STEP 7. In the
following, it is assumed that the user is already familiar with
the contents of the manual for the COM PROFIBUS software
or for STEP 7.
2.2.1 Preparations for COM PROFIBUS 3.x and 5.0
Device data base
CD ROM
1. Copy the device data bases of the valve terminals into
the following directory on your programmer/PC:
- COM PROFIBUS 3.x: \COMPB3x\GSD
- COM PROFIBUS 5.0: \SIEMENS\CPBV50\GSD
The device data base can be found on the accompanying
CD ROM:
VI10F13C.GSD
Please note
Update the slave catalogue, if you copy the device data
base during work with COM PROFI BUS.
Menu: “File” - “Load GSD file”.
