2. Commissioning
2-14
Festo Festo P .BE CP FB13-E-EN en 9910c
Symbols 2. In order to simplify configuration, there are files on the
CD ROM with symbols of the valve terminals. Copy the
device data base of the valve terminals into the following
directory on your programmer/PC:
- COM PROFIBUS 3.x: \COMPB3x\BITMAPS
File: PBFB13CN.BMP
- COM PROFIBUS 5.0: \SIEMENS\CPBV50\BITMAPS
File: PBFB13CN.DIB
3. After selecting the master/host system, process the mask
“Bus parameter” in the menu “Configure”
– Bus profile
– Baud rate
Further information (directories, etc.) can be found in the file
“readme” in the main directory of the CD ROM.
