2. Commissioning
2-40
Festo Festo P .BE CP FB13-E-EN en 9910c
The composition of the identifier bytes can be found in sec-
tion 2.1.4.
Summary of parameters (Chk_Cfg):
Octet 1-n: DP identifier
Permitted identifiers for Festo CP systems
in compact mode (see also Fig. 2/5).
Number of
I/Os
Decimal inputs Decimal outputs
up to 16 017 033
up to 32 019 035
up to 48 021 037
up to 64 023 039
Example:
Configuring a CP system with 32 inputs/outputs in standard
mode.
Configuration Function: Chk_Cfg
String
Octet DP identifier
decimal hex
0 1 049 031
1 2 049 031
