Components
104 © Festo Didactic Conveyor
Position
Description
1
Outside guard railing
2
Turning table
3
Inside guard railing
4
Motor
5
Coupling sensor transmission
6
Coupling sensor transmission
7
Screw
8
Motor connection (see Circuit diagram p.13)
