Design and function
52 © Festo Didactic Conveyor
4.8.3 Motor version 400V
Motor MA1 – Clamps
G120 CU240-2PN / QA1- Clamps
U1 / W2
X1:1
V1 / U2
X1:2
W1 / V2
X1:3
PE / PE
X1:PE
