Design and function
© Festo Didactic Conveyor 51
4.8.2 Motor version 230V
Configured in triangle.
Motor MA1 – Clamps
G120 CU240-2PN / QA1- Clamps
U1
X1:1
V1
X1:2
W1
X1:3
PE
X1:PE
