5 Commissioning
NOTICE
The following applies to the start-up as well as to the restart.
 The CP Application Module is delivered pre-assembled.
 All attachment parts are individually packaged.
 All components, tubings and cablings have been clearly marked in order to guarantee a problem-free
retrieving of all connections.
 For the operation within a CP Factory/Lab System, the CP Application Module has to be put on and
attached to a basic module.
NOTICE
You can read the general installation instructions in the manual of your basic module. The
following instructions apply particularly to the CP Application Module.
5.1 Workplace
The commissioning of the CP Application Module requires:
 a CP Application Module
 a basic module CP Factory or a basic module CP Lab Conveyor for the installation of the CP Application
Module
 a SysLink cable for the connection between the I/O terminal of the CP Application Module and the basic
module CP Factory
 an Ethernet cable for the connection of the motor controller (option)
 an on-site electrical connection in the room, see data sheet basic module
 an on-site pneumatically connection in the room, see data sheet basic module
