Components
© Festo Didactic Conveyor 109
Position
Description
1
Switch S1
2
Switch S2
If the docking extension is used for the robotino, the two toggle switches S1 and S2 must be changed over.
Left position - encoder is used / docking extension deactivated
Right position - Encoder is not used / docking extension activated
