Design and function
38 © Festo Didactic Conveyor
Pallet transfer system front view
Position
Description
Position
Description
1
Carrier
6
Scalance Ethernet switch (optional)
2
On-off valve
7
Control panel / Touch panel (optional)
3
Capacitive sensor start of conveyor
8
Basic frame
4
Conveyor
9
Control cabinet for electrical components and controlling
5
Coupling sensor previous station
