Design and function
66 © Festo Didactic Conveyor
Description Interface Inputs
Name
Clamp at ET200 SP
SysLink cable
SysLink plug
Application IN0
KF2 / clamp: 1 (l0)
WG21 / GYPk
XG2: 1
Application IN1
KF2 / clamp: 2 (l1)
WG21 / RDBU
XG2: 2
Application IN2
KF2 / clamp: 3 (l2)
WG21 / WHGN
XG2: 3
Application IN3
KF2 / clamp: 4 (l3)
WG21 / BNGN
XG2: 4
Application IN4
KF2 / clamp: 5 (l4)
WG21 / WHYE
XG2: 5
Application IN5
KF2 / clamp: 6 (l5)
WG21 / YEBN
XG2: 6
Application IN6
KF2 / clamp: 7 (l6)
WG21 / WHGY
XG2: 7
Application IN7
KF2 / clamp: 8 (l7)
WG21 / GYBN
XG2: 8
Description Interface Outputs
Name
Clamp at ET200 SP
SysLink cable
SysLink plug
Application OUT0
KF4 / clamp: 1 (O0)
WG21 / WH
XG4: 1
Application OUT1
KF4 / clamp: 2 (01)
WG21 / BN
XG4: 2
Application OUT2
KF4 / clamp: 3 (02)
WG21 / GN
XG4: 3
Application OUT3
KF4 / clamp: 4 (03)
WG21 / YE
XG4: 4
Application OUT4
KF4 / clamp: 5 (04)
WG21 / GY
XG4: 5
Application OUT5
KF4 / clamp: 6 (05)
WG21 / PK
XG4: 6
Application OUT6
KF4 / clamp: 7 (06)
WG21 / BU
XG4: 7
Application OUT7
KF4 / clamp: 8 (07)
WG21 / RD
XG4: 8
Description Interface Voltage
Name
SysLink cable
SysLink plug
24VB
WG21 / WHPK
XZ1/X11: VB
0VB
WG21 / WHBU
XZ1/X11: 0 XZ1/X11: 0V
24VA
WG21 / BK
XZ1/X11: VA
0VA
WG21 / PKBN
XZ1/X11: 0V
0VA
WG21 / PUR
XZ1/X11: 0V
