Components
© Festo Didactic Conveyor 99
ET200SP with IM155
ET200 SP
Position
Description
1
ET200SP / IM155-6 PN HF / K1-KF1 / 6ES7155-6AU00-0CN0
2
DI / 8x 24VDC / K1-KF2 / 6ES7131-6BF00-0CA0
3
DI / 8x 24VDC / K1-KF3 / 6ES7131-6BF00-0CA0
4
DO / 8x 24VDC 0,5A / K1-KF4 / 6ES7132-6BF00-0CA0
5
DO / 8x 24VDC 0,5A / K1-KF5 / 6ES7132-6BF00-0CA0
6
CM / 4x IO-Link ST / K1-KF6 / 6ES7137-6BD00-0BA0
