SERVICING THE E-41 WITH FURNITURE 147
REMOVING THE E-41 FROM THE FURNITURE
WARNING: Never lift the E-41 by grasping the top panel. The top panel does not support the
weight of the system.
1. Make sure that the E-41 is shut down and that all the cables are removed from the back of the
E-41.
2. Remove the cable cover and disconnect the two monitor cables (power and video):
• Power—from the back of the monitor and from the wall outlet
• Video—from the back of the monitor and from the back of the E-41
Video cable
Cable cover
Power cable
