Fiery E-41 - Page 148

SERVICING THE E-41 WITH FURNITURE 148
3. Remove the thumbscrews that attach the E-41 stability bracket to the stand.
4. Lift the bracket and gently pull the E-41 away from the table top.
Make sure to pull the E-41 out just enough so that the front panel of the E-41 is aligned with
the back edge of the table top.
Stability bracket
Thumbscrews
