SERVICING THE E-41 WITH FURNITURE 150
6. Use the allen key to loosen the screw that secures the monitor pole to the E-41.
The allen key should be stored in the side drawer of the furniture.
7. Holding the monitor pole, gently lift the monitor pole assembly up and out of the E-41
monitor mount.
8. Continue with the procedure “To open the E-41” on page 51.
Allen key
Monitor pole
