3.10.2 DISABLING THE CUTTING UNIT
With reference to Figure 23, to use the machine as a sheeter whilst keeping the cutting unit mounted, simply
release the cutting unit from the system that secures it to the table by lifting the release bar ref. 1 (to make this
easier, push the unit down with one hand).
WARNING! To prevent the unit from being raised too quickly (pushed by the lateral gas springs ref. 2) and
risk being hit and bruised by it, guide it by hand as it is raised. In the event that the gas springs may be
discharged, place the unit well back to prevent it from falling and subject persons to the risk of severe
bruises and cuts and bruises. If you notice that one or both gas springs no longer provide an adequate
braking function, replace it/them immediately (simply remove the two screws ref. 3 at the ends). Only use
original Flamic spare parts.
The maximum thickness of dough that can pass under the cutting unit is 55 mm.
Figure 23 - Disabling the cutting unit
1 2 3
