List of the wooden parts
DESCRIPTION
reference image
Part 17
Steering column Bracket
PLYWOOD SHEET 2
Part 18
Steering Pinion Mount
PLYWOOD SHEET 2
Part 19
Steering column Shaft
PLYWOOD SHEET 2
Part 20
Steering Pinion
PLYWOOD SHEET 1
Part 21
Steering Wheel
PLYWOOD SHEET 2
Part 22
Seat Side Left
PLYWOOD SHEET 3
Part 23
Seat Side Right
‒ gas tank side
PLYWOOD SHEET 3
Part 24
Seat Crossbar
PLYWOOD SHEET 1
List of the wooden parts
DESCRIPTION
reference image
Part 25
Seat Crossbar
PLYWOOD SHEET 3
Part 26
Seat Crossbar
PLYWOOD SHEET 3
Part 27
Seat Crossbar Bracket
PLYWOOD SHEET 3
Part 28
Seat Bolster Left
PLYWOOD SHEET 4
Part 29
Seat Bolster Right
PLYWOOD SHEET 4
Part 30
Seat Thigh Bolster Left
PLYWOOD SHEET 4
Part 31
Seat Thigh Bolster Right
PLYWOOD SHEET 4
Part 32
Seat Back
PLYWOOD SHEET 4
