1 50718 P LY F LY rev A_EM | August 7, 2015 5:06 PM

List of the wooden parts

DESCRIPTION

reference image

Part 33

Seat Bottom

PLYWOOD SHEET 4

Part 34

Brake Pedal

PLYWOOD SHEET 1

Part 35

Gas Pedal

PLYWOOD SHEET 3

Part 36

Pedal Side

PLYWOOD SHEET 1

Part 37

Pedal Side

PLYWOOD SHEET 1

Part 38

Pedal Side

PLYWOOD SHEET 1

Part 39

Pedal Side

PLYWOOD SHEET 1

Part 40

Frame Rail Inner Left

PLYWOOD SHEET 1

List of the wooden parts

DESCRIPTION

reference image

Part 41

Frame Rail Inner Right

PLYWOOD SHEET 1

Part 42

Frame Rail Outer Left

PLYWOOD SHEET 1

Part 43

Frame Rail Outer Right

PLYWOOD SHEET 1

Part 44

Frontend Bottom

PLYWOOD SHEET 2

Part 45

Frontend Top

PLYWOOD SHEET 2

Part 46

Frame Rail Bracket

PLYWOOD SHEET 2

Part 47

Sprocket Guard

PLYWOOD SHEET 3

Part 48

Frame Rail Rear

PLYWOOD SHEET 2

64

11 Master List
