11 Displaying measured values FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 111
11.2.2 HumanMux mode
In the HumanMux mode, the measured values of one channel are displayed. The measurement on the other channels is
continued, but not displayed.
Select the command →Mux:Nextchan.to display the next activated channel. The measured values of the selected chan-
nel will be displayed as configured in the program branch Output Options (see section 11.1).
11.3 Adjustment of the display
During the measurement, the display can be adapted in order to display 2 measured values simultaneously (one in each
line of the display). This does not affect totalizing, storing of measured values, transmission of measured values, etc.
The following information can be displayed in the upper line:
The measured values of the physical quantity selected in the program branch Output Options can be displayed in the
lower line:
Press key during the measurement to change the display in the upper line, press key to change the display in the
lower line.
The selected channel is displayed left in the upper line.
display explanation
Mass Flow= designation of the physical quantity
A: +8.879 m3 values of the totalizers
full= date and time at which the data logger will be full, if activated
Mode= measuring mode
L= transducer distance
Compress= compressibility coefficient of the gas
Rx= alarm state indication if it is activated (see section 17.7.5) and if alarm outputs are activated (see
section 17.6).
δc= difference between the measured sound speed and the sound speed of a selected reference fluid, if
activated (see section 15.3)
status line (see section 11.4)
display explanation
12.3 m/s flow velocity
1423 m/s sound speed
124 kg/h mass flow rate
15 m3/h volumetric flow rate
The character * indicates that the displayed value (here: flow velocity) is not the selected
physical quantity.
B:Flow Velocity
1.25 m/s
A:Flow Velocity
* 2.47 m/s
