16 SuperUser mode FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 147
For setting the behavior of the totalizers when the max. value is reached see section 12.3.1.
16.8 Manual reset of the totalizers
If the manual reset of the totalizers is activated, the totalizers can be reset to zero during the measurement by pressing 3
times key CLR, even if a program code is activated.
Select Special Funct.\SYSTEM settings\Measuring\Miscellaneous. Press ENTER until the menu item 3xC
clear totals is displayed.
16.9 Display of the totalizer sum
The sum of the totalizers for the two flow directions can be displayed in the upper line during the measurement.
Select Special Funct.\SYSTEM settings\Measuring\Miscellaneous. Press ENTER until the menu item Show
Q is displayed.
16.10 Display of the last valid measured value
If the signal is not sufficient for a measurement, UNDEF is normally displayed. Instead of UNDEF, it is also possible to dis-
play the last valid measured value.
Select Special Funct.\SYSTEM settings\Measuring\Miscellaneous. Press ENTER until the menu item Keep
display val is displayed.
16.11 Display during the measurement
In the SuperUser mode, the following information can be displayed during the measurement besides the normal informa-
tion (see section 11.3):
Note!
The number of decimal places and the max. value defined here only affect the display of the totalizers
.
Select on to activate the manual reset of the totalizers, off to deactivate it. Press ENTER.
Note! The manual reset of the totalizers is still active after the deactivation of the SuperUser mode.
Select on to activate the display of the sum of the totalizers, off to deactivate it.
Press ENTER.
If the display of the totalizer sum is activated, the sum Q can be displayed in the upper line
during the measurement.
Select on to activate the display of the last valid measured value, off to deactivate it.
Press ENTER.
display explanation
t= transit time of the measuring signal
c= sound speed
REYNOLD= Reynolds number
VARI A= standard deviation of the signal amplitude
VARI V= standard deviation of the transit time of the measuring signal
dt-norm= transit time difference standardized to the transducer frequency
density of the fluid
3xC clear totals
off >ON<
Show Q
off >ON<
Q 13.2 m3
Keep display val
off >ON<
