17 Outputs
If the transmitter is equipped with outputs, they have to be installed and activated before they can be used:
• assignment of a measuring channel (source channel) to the output (if the transmitter has more than one measuring channel)
• assignment of the physical quantity (source item) to be transmitted to the output by the source channel, and of the prop-
erties of the signal
• definition of the behavior of the output in case no valid measured values are available
• activation of the installed output in the program branch Output Options
17.1 Installation of an output
All outputs are installed in Special Funct.\SYSTEM settings\Proc. outputs.
The source items and their scroll lists are shown in Tab. 17.1.
Note! The configuration of an output will be stored at the end of the dialog. If the dialog is quit by pressing
key BRK, the changes will not be stored.
Select Special Funct.\SYSTEM settings\Proc. outputs. Press ENTER.
Select the output to be installed. Press ENTER.
The scroll list contains all available outputs. A tick after a list item indicates that this out-
put has already been installed.
Select yes to install or reconfigure the output. Press ENTER.
Select no to uninstall the output and to return to the previous menu item in order to select
another output. Press ENTER.
Select in the scroll list the measuring channel to be assigned to the output as the source
channel. Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
Select the physical quantity (source item) to be transmitted from the source channel to the
output.
If a binary output is configured, only the list items Limit and Impuls will be displayed.
Tab. 17.1: Configuration of the outputs
source item list item output
Measuring value actual measure physical quantity selected in the program branch Output Options
flow flow, independent of the physical quantity selected in the program
branch Output Options
Quantity Q+ totalizer for the positive flow direction
Q- totalizer for the negative flow direction
Q sum of the totalizers (positive and negative flow direction)
Limit R1 limit message (alarm output R1)
R2 limit message (alarm output R2)
R3 limit message (alarm output R3)
Impuls from abs(x) pulse without sign consideration
from x > 0 pulse for positive measured values
from x < 0 pulse for negative measured values
SYSTEM settings↕
Proc. outputs
Install Output ↕
Current I1 ()
I1 enable
no >YES<
I1 Source chan.↕
Channel A:
I1 Source item ↕
Measuring value
