FLUXUS F808, F809 6 Installation of FLUXUS F808
28 UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23
6.4 Connection of the transmitter
Attention! Observe the Safety Instructions for the Use in Explosive Atmosphere (see document SIFLUXUS,
SIFLUXUS_808_FM,SIFLUXUS_808_F2 and SIFLUXUS_1N62).
Attention! The degree of protection of the transmitter will only be ensured if the cable glands are firmly tightened
and the housing covers are tightly screwed to the housing.
Fig. 6.4: Connections of the transmitter
KL1
KL3
KL4 KL2
power supplyoutputs
transducers
equipotential
bonding terminal
