17 Outputs FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 149
17.1.1 Output range
17.1.2 Error output
In the following dialog, an error value can be defined which is to be output if the source item cannot be measured, e.g., if
there are gas bubbles in the fluid.
Miscellaneous c-Medium sound speed of the fluid
SCNR ratio useful signal to correlated disturbance signal
Signal signal amplitude of a measuring channel
VariAmp standard deviation of the signal amplitude
Density density of the fluid
Pressure pressure of the fluid
During the configuration of an analog output, the output range is defined. Select a list item
or other range... to enter the output range manually.
If other range... has been selected, enter the values Output MIN and Output MAX.
Press ENTER after each input.
This error message will be displayed if the output range is not min. 10 % of the max. output
range. The next possible value will be displayed. Repeat the input.
example: I
MAX
- I
MIN
2 mA for a 4…20 mA current output
Tab. 17.2: Error output
error value result
Minimum The lower limit of the output range is transmitted.
Hold last value The last measured value is transmitted.
Maximum The upper limit of the output range is transmitted.
Other value... The value has to be entered manually. It has to be within the limits of the output.
Tab. 17.1: Configuration of the outputs
source item list item output
I1 Output range↕
4/20 mA
I1 Output MIN ↕
10.0 mA
I1 Output MAX ↕
11.0 mA
I1 Output MAX ↕
12.0 minimal
