Install Material
selection of the displays for the input of the pipe and lining materials
Install Material with Special Funct.\SYSTEM settings\Libraries\Extended Library = off
selection whether a user defined material is to be edited or deleted
selection of a user defined material
input of a designation for the selected material
input of the sound speed of the material
range: 600...6553.5 m/s
input of the roughness of the material
Install Material with
Special Funct.\SYSTEM settings\Libraries\Extended Library = on
selection of the function for the temperature and pressure dependence of the
material properties
selection of a user defined material
selection whether the user defined material is to be edited or deleted
This display will only be indicated if the selected material already exists.
input of a designation for the selected material
input of the constants for the transversal sound speed of the material
The number of constants depends on the function selected above.
input of the constants for the longitudinal sound speed of the material
The number of constants depends on the function selected above.
selection of the sound wave type for the flow measurement
input of the roughness of the material
confirmation that the changes are to be stored
This display will only be indicated if a new material has been entered or the
properties of an existing material have been changed.
INIT-
resistant
Special Funct. ↕
Install Material
Install Material
>EDIT< delete
USER Material ↕
#01:--not used--
EDIT TEXT (↑↓← →
USER MATERIAL 1
c-Material
1590.0 m/s
Roughness
0.4 mm
Edit Material ↕
Basics:Y=m*X +n
USER Material ↕
#01:--not used--
USER Material 2
>EDIT< delete
#2: Input Name:
USER MATERIAL 2
T-SOUNDSP.
1500.0 m/s
L-SOUNDSP.
1500.0 m/s
Default soundsp.
long. >TRANS.<
Roughness
0.4 mm
Save changes
no >YES<
To Next Page
