Flexim FLUXUS F808 A1 Series User Manual

5 Selection of the measuring point FLUXUS F808, F809
UMFLUXUS_F808_8091V1-2-1EN, 2019-08-23 23
disturbance source: reducer
supply line: l ≥ 10 D return line: l ≥ 5 D
disturbance source: pump
supply line: l ≥ 20 D
Tab. 5.2: Recommended distance from disturbance sources;
D - nominal pipe diameter at the measuring point, l - recommended distance between disturbance source and transducer position
l
l
l
P
