8 Start-up
FLUXUS WD 8.4 Program branches
71
UMFLUXUS_WDV1-3EN, 2018-07-16
8.4 Program branches
The following schema shows the program branches. For a detailed overview of the menu structure see annex A.
8.5 Language
The language of the transmitter can be selected:
• Select the menu item Language in the program branch Special functions\System settings.
• Press ENTER.
• Select the desired language from the scroll list.
• Press ENTER.
Afterwards the menu will be displayed in the selected language. The selected language remains activated when the trans-
mitter is switched off and on again.
The language can also be changed by entering a HotCode.
8.6 Initialization
During an initialization (INIT) of the transmitter, all settings are reset to the factory default settings.
Proceed as follows to execute an initialization:
• When switching on a transmitter: keep keys and C pressed.
• During the operation of the transmitter: press keys , C and ENTER simultaneously. Release only key ENTER. Keep
keys and C pressed.
During an initialization it is tested whether the key lock is activated. If so, it has to be deactivated.
• Enter a 6-digit key lock code.
• Press ENTER.
If a measurement is currently running, it will be stopped.
It will be requested whether the initial settings are to be carried out.
Parameters Measurement Options Special functions
Selection of a measuring
channel
Selection of measuring
channels
Selection of a measuring
channel
System settings
Transducer parameter Measuring point number Physical quantity Outputs
Pipe parameters Number of sound paths Units of measurement Measurement
Fluid parameter Transducer distance Outputs Data logger
Length of extension cable Diagnostic values Remote functions Snaps
Transducer positioning Event trigger Communication
Measurement Special settings Units of measurement
Totalizers
Dialogs/menus
Parameter record
Libraries
Minimum pipe diameter
Special functions\System settings\Language
