9 Measurement
9.1 Parameter input FLUXUS WD
2018-07-16, UMFLUXUS_WDV1-3EN
74
•Select Select transducer to use the standard transducer stored in the transmitter.
• Select the transducer.
• Press ENTER.
This display will only be indicated if the transducers and the sensor module are connected to the transmitter.
9.1.2 Input of pipe parameters
Outer pipe diameter
• Enter the outer pipe diameter.
• Press ENTER.
It is possible to enter the pipe circumference instead of the outer pipe diameter.
Pipe circumference
• Activate the input of the pipe circumference.
• Press key in the menu item Outer diameter. The menu item Pipe circumference will be displayed.
• Enter the pipe circumference.
• Press ENTER.
If the outer pipe diameter is to be entered, press key . The menu item Outer diameter is displayed.
Pipe material
The pipe material has to be selected to be able to determine the corresponding sound speed.
The sound speeds for the materials in the scroll list are stored in the transmitter.
• Select the pipe material.
• Press ENTER.
• If the material is not in the scroll list, select Other material.
• Press ENTER.
Parameters\Select transducer
If a standard transducer is selected, no transducer-specific calibration values are considered. A higher uncertainty
has to be expected.
Parameters\Outer diameter
Parameters\Pipe circumference
Parameters\Pipe material
