Getting started
Operators manual 13
FDS 400-301
A caution is a type of note that advises you that failure to take or avoid a specific action
could result in damage or loss of data. For example:
A menu sequence shows you how to open a series of menus. For example:
3.2 Using the HHMPI To download data from a Flight Data Recorder (FDR) or Cockpit Voice Recorder (CVR), you
need the following equipment:
The HHMPI kit, see Figure 6.0, ”HHMPI kit”, on page 9.
An interface cable for the specific recorder you want to download data from, see
Table 4.0, “Interface cables and software options,” on page 10.
3.2.1 Connecting the HHMPI to an FDR
To connect the HHMPI to a recorder use the interface cable for the specific recorder you
want to download data from. Power is often supplied through the interface cable to the
HMMPI from an aircraft powered recorder. In this configuration it is safe to connect or
disconnect the HHMPI. See Figure 7.0, ”Connecting the HHMPI to the FDR or CVR”, on
page 14.
Caution Before applying power, verify that the product is set to
match the line voltage and the correct fuses are installed.
▼▲
Main Menu >Device Configuration > Settings Profile > Save Aircraft >
USB Flash Drive
