Flight Data Systems HHMPI - FDR Status; CVR Status; FDR or CVR Fault Output; Clear Latched Fault

FA2100, FA2200 and FA2300 Interface Supplement
Operators manual 49
FDS 400-301
 Clearing of latched faults and fault log.
 Download of CVFDR fault logs. See Figure 37.0, ”FA2100 Recorder Operations - Dump
Debug Trace”, on page 49.
8.3 FDR Status Indicates the status of the following:
 FDR Stream Detected
 Frame Lock
 Recorded Minutes
 Latched
 Fault
8.4 CVR Status Indicates the status of the following:
 Latched
 Fault
 Recording
8.5 FDR or CVR Fault
Output
The cockpit fault light can be forced on or off using the left and right buttons.
8.6 Clear Latched Fault Sets or reset the fault log.
8.7 Clear Fault Log Erases the fault log.
8.8 Dump Fault Log Saves the fault log to selected memory. See Figure 37.0, ”FA2100 Recorder Operations -
Dump Debug Trace”, on page 49.
Figure 37.0 FA2100 Recorder Operations - Dump Debug Trace
8.9 Dump Debug Trace This function dumps the running debug stream from an L3 FA2100 recorder to a file on
the HHMPI. This file is a text file readable in any text editor.
8.10 Memory Marker Set a new FDR memory marker. The next marker will be chosen in the range 1-15, when
all the markers are set, the marker count returns to 1.
