Flight Data Systems HHMPI - Page 59

FA5000/FA5001 Interface Supplement
Operators manual 59
FDS 400-301
Recorder Operations FDR Status FDR Fault
FDR Input Data Lock
ARINC 717 Data Received
Current FDR Rate
Latest FDR Marker
CVR Status CVR Fault
Datalink Data Received
GMT Data Received
OMS Data Received
Rotor Data Received
CAM Audio Present and Send-
ing Data
MIC1 Audio Present and Send-
ing Data
MIC1 Audio Present and Send-
ing Data
MIC1 Audio Present and Send-
ing Data
Latest CVR Marker
Set FDR Marker Memory Marker - in progress or
marker number
Set CVR Marker Memory Marker - in progress or
marker number
Dump Log List of storage devices
Get EDS File List of storage devices
FDR Configuration Information Recorder Part Number
Aircraft ID
Recorder Serial Number
Date(YYYY/MM/DD)
Time(HH:MM:SS:MS)
FW Version
L3 HW FPGA Part Number
L3 HW FPGA Part Number
Revision
L3 FW FPGA Part Number
L3 FW FPGA Part Number Revi-
sion
L3 FPGA FW Date (DD/MM/
YYYY)
PN Unknown1
PN Unknown2
Audio Operations CVR Live Audio Select Monitor Channel: HQV1,
HQV2, HQV3, SQN, SQC, HQC.
Audio volume
Data Rate
CVR Playback Select Playback Channel:
HQV1, HQV2, HQV3, SQN,
SQC, HQC.
Playback status
Playback audio volume
Playback data Rate
Live Data View (Section 4.4,
”Viewing live flight data” on
page 26)
View Live Data
View Captains Clock Label 150 Clock (HH:MM:SS)
Label 125 Clock (HH:MM:SS)
View Rotor Raw Rotor Frequency
Table 12.0 Additional menu items for FA5000/FA5001 CVFDR
Main Menu Menu Level 1 Menu Level 2
