Flintec FT-111 D - Programming and Parameters

FT-111(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 43 of 146
6.4 Programming and Parameters
FT-111 weighing indicator is programmed under the seven main blocks in the programming menu which are
serial interface, configuration, application, scale, calibration, metrology and diagnostic.
Main blocks in the programming menu are displayed like [1-- INTERFACE ] and sub-blocks are displayed like [11-
RS232C ]. Parameters are located in the sub-blocks like [111 FORMAT: CONT ].
You can move in the blocks by pressing or keys. After reaching the desired block, press key or key to
enter it. After arriving the parameter to change, you may change its function by pressing or keys. If the value will
be entered to the parameter press key to increase or press key to decrease the blanking digit and press or
key to select digit then press , press key to go to the following parameter.
For example, to change the Baud rate of RS422 serial interface to 57600;
1. After entering the programming, the [1-- INTERFACE ] sub-block prompt appears. Press key.
2. [11- RS232C ] prompt appears. Press key until [13- RS422 ] appears.
3. Press key until [132 BAUD: 9600 ] appears.
4. Press key until [132 BAUD: 57K6 ] appears.
5. Press key to enter the next parameter.
Legally related parameters can be changed if the calibration dip switch is at ON position. The values of these parameters
limited according to the OIML against wrong set up. Legally related parameters are marked with M symbol in the table
below.
