FT-111(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 53 of 146
[
19-
ETHERNET IP
]
ETHERNET/IP CONFIGURATION (Only FT-111 EI)
Press key or key again to enter this menu.
Press key to go to beginning of the sub-block or press
key to go to the next main-block.
[
191
FORMAT
:
INTG
]
Data format of the EtherNet/IP
INTG
FLOA
:
:
Signed 32 bit integer, no decimal point
implied.
32 bit float, decimal point implied.
[
192
IP
:
250
]
IP address of Ethernet port.
Default is 192.168.16.250
[
194
SUB MASK
:
000
]
Subnet mask address of Ethernet port.
Default is 255.255.255.000
[
195
GATEWAY
:
253
]
Gateway address.
Default is 192.168.16.253
[
19A
MAC ADR
:
]
MAC address
AA:BB:CC:DD:EE:FF
[
19-
ETHERCAT
]
ETHERCAT CONFIGURATION (Only FT-111 EC)
Press key or key again to enter this menu.
Press key to go to beginning of the sub-block or press
key to go to the next main-block.
[
191
FORMAT
:
INTG
]
Data format of the EtherCAT
INTG
FLOA
:
:
Signed 32 bit integer, no decimal point implied.
32 bit float, decimal point implied.
[
19-
CC-LINK
]
CC-LINK CONFIGURATION (Only FT-111 CC)
Press key or key again to enter this menu.
Press key to go to beginning of the sub-block or press
key to go to the next main-block.
[
191
FORMAT
:
INTG
]
Data format of the CC-Link
INTG
FLOA
:
:
Signed 32 bit integer, no decimal point implied.
32 bit float, decimal point implied.
[
192
ADDRESS
:
001
]
Node address
001…64
[
193
BAUD
:
156K
]
Baud rate
156K
625K
2.5M
5M
10M
:
:
:
:
:
156 kbps
625 kbps
2.5 Mbps
5 Mbps
10 Mbps
