FT-111(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 80 of 146
THR-LOW Threshold, active low
Output goes to low if net weight is heavier
than setpoint high. Returns the high if the
weight is less than setpoint low.
VIN-HI Window, active high
Output goes to high if net weight is between
setpoint high and setpoint low.
VIN-LOW Window, active low
Output goes to low if net weight is between
setpoint high and setpoint low.
