FT-111(D) Panel Weighing Indicator, Technical Manual, Rev.1.0.0, May 2019 Page 84 of 146
Entry the limit values
1. Press the key.
2. The setpoint 1 value appears as shown on the display [ SP 1 1250 kg ].
3. Press key to increase or press key to decrease the blanking digit and press or key to
select a digit. You may press key to enter negative setpoint value. Press the key to save it
and to go to the next setpoint.
4. Repeat from step 2 for entering following setpoints.
5. The indicator returns to the operation after displaying setpoint 5 and entering its value,
6. Press key to return operation at any step.
Entry setpoint of items into SET memory
1. Press key for more than 2 seconds. [ MEMORY ] prompt appears.
2. Press key. The last used Set memory group number appears [ SET : 111 ].
3. Enter the new memory code by pressing key to increase or press key to decrease the
blanking digit and press or key to select a digit and press key to enter the item.
4. The first limit value is appear on the display as [ SET 111 - SP1 ] [ 10.00 kg ]. Enter the new value
by numerical keys and press the key.
5. The following limit value appears as [ SET 111 - SP2 ] [ 20.00 kg ]. Enter new value by pressing
key to increase or press key to decrease the blanking digit and press or key to select
digit and press the key.
6. Repeat step 4 and 5 until entering values to other three limit value of the group.
7. After entering the value of 5th setpoint value press key to go next memory code.
8. Or press key to exit.
Select limits of item from SET memory
1. Press key. The last used setpoint value appears on the display [ SP1 1250 kg ].
2. Press key for more than 2 seconds. The last used Set memory code appears on the display
[ SET : 111 ].
3. Enter the memory code of the item by pressing key to increase or press key to decrease
the blanking digit and press or key to select a digit and press key.
4. The selected Set memory data is loaded after displaying values.
5. Or press key to exit without loaded.
