Set up the Calibrator
The remaining sections of this chapter explain how to set up the Calibrator.
Setup Menu
The Setup Menu grants access to various operations and changeable Calibrator
parameters. Once a parameter is set, it is saved in memory until it is changed. Any
changes are saved during power-off periods.
When Setup Menu is touched from the normal operation screen, the display shows the
Setup Menu:
Calibration
DC Zero
Artifact Calibration
Calibration Check
Wideband Gain Calibration
Wideband Flatness Calibration
Change Calibration Password
Range Adjustment
Generate Report
Instrument Setting
Date/Time Format
Language
Display
Self Test & Diagnotics
Diagnostics
Key, Knob, and Bell Tests
Instrument Setup
Remote Port
Uncertainty Information
Output Limits
Sourcing Hardware
Error Reference
Exit
About this Instrument
Setup Menu
hhp104.eps
The subsequent list briefly describes the submenus available from the Setup Menu.
• Calibration- The items in this submenu are used to activate calibration to external
standards, Calibration Check, DC Zeros, and to verify or adjust the 5730A Calibrator
calibration to its specifications. The Calibration submenu and process is explained in
greater detail in Chapter 7.
• Self Test & Diagnostics- Use this submenu to do automatic internal self-diagnostics
on various features of the Calibrator. Once started, the self-diagnostic cannot be
interrupted. The Calibrator must be completely warmed up to run the self-diagnostics
or the process will timeout and prompt to let the Calibrator warm up.
The submenu also has a Key, Knob, and Bell Test that can be run from this point. The
key and knob test take input from the front-panel keys and rotary knob and return visual
identifiers that the key being pushed returns what it should. For example, if is
pushed, “Enter” is returned in the blank field of the submenu. When Run Bell Test is
pushed, an internal bell will sound.
