Front-Panel Operation
Set the Output 4
4-21
AC Current Output
To set an ac current output:
1. Make sure the Calibrator is in standby (STANDBY annunciator lit). Push if
necessary.
2. If the UUT is not connected, connect it now as described earlier in this chapter under
“Connect the Calibrator to a UUT.”
3. Set the UUT to measure ac current on the appropriate range.
4. Enter a current magnitude with the numeric keypad.
5. Push or if necessary.
6. Push .
7. The display now shows the amplitude of the entry. If an entry error is made, push
to clear the display, then reenter the value. If the most recent digit entered is in error,
push to clear that digit. The illustration of the display below assumes an entry of
125 mA:
+/- 0.00050mV (1 year) 213 days since calibration
3/14/2013 10:52am
External
Sense
OFF
External
Guard
OFF
Wideband
OFF
Setup
Menu
Operate
mV
0.00000
Auto Range 220 mV
125mA
External
Sense
OFF
hhp119.eps
