DC Voltage Output
To set a dc voltage output:
1. Make sure the Calibrator is in standby (STANDBY annunciator lit). Push  if
necessary.
2. If the UUT is not connected, connect it now as described in this chapter under
“Connect the Calibrator to a UUT.”
3. Set the UUT to measure dc voltage on the necessary range.
4. Enter a voltage value with the numeric keypad.
5. To change the polarity of the entry, push .
6. Push , , or  if necessary.
7. Push .
8. The display now shows the amplitude of the entry. If an entry error is made, push 
to clear the display, and then reenter the value. If the most recent digit entered is in
error, push  to clear that digit. The display shown below assumes an entry of
10 mV.
+/- 0.00050mV (1 year) 213 days since calibration
3/14/2013 10:52am
External
Guard
OFF
Wideband
OFF
Setup
Menu
Standby
mV
0.00000
Auto Range 220 mV
10mV
External
Sense
OFF
hhp113.eps
9. Push . The Calibrator clears the entry from the entry bar toward the bottom
and shows in the larger area above. No voltage is available at the output terminals
until  is pushed.
10. Push to activate the Calibrator output. The UUT will respond to the applied
voltage.
In dc voltage output mode, the selections available at the bottom are:
• External Sense
• External Guard
• Wideband
• Setup Menu
In addition, the Offset and Scale functions are available. The output range can be
locked in dc volts.

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
