Fluke 5730A User Manual

5730A
Operators Manual
4-2
Turn on the Calibrator
Warning
To avoid electric shock, make sure the Product is safely
grounded as described in Chapter 2.
Make sure the rear power switch is on and then push to turn on the 5730A
Calibrator. When the Calibrator is turned on, it takes approximately 50 seconds to
complete its power-up process.
After the power-up process, the display shows the normal operation screen:
+/- 0.00050mV (1 year) 213 days since calibration
12/21/12 10:52am
External
Sense
OFF
External
Guard
OFF
Wideband
OFF
Setup
Menu
Standby
mV
0.00000
Auto Range 220 mV
hhp102.eps
The Calibrator is in standby mode with the internal sensing and internal guard
configured. The Calibrator can now accept entries from the front panel.
Warmup
Make sure the 5730A Calibrator is warmed up before use. The environmentally-
controlled components inside must be stable to meet or exceed the specifications in
Chapter 1. Sufficient warmup times are:
• If the Calibrator has been powered off for 1 hour or more, allow at least 30 minutes
of warmup time.
• If the Calibrator has been powered off for a length of time less than 1 hour, allow it to
warm up for at least twice the length of time it was turned off. For example, if it has
been powered off for 10 minutes, allow at least 20 minutes of warmup time.
Product Use
Touchscreen navigation is used to move throughout the 5730A Calibrator user interface
(UI) and menus.

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
