Fluke 5730A User Manual

Introduction and Specification
Electrical Specifications 1
1-29
Maximum Output Compliance Voltage ............... 4.5 V rms (6.4 V pk), 6.4 V dc. 120 A range maximum compliance
voltage decreases from 4.5 V at 1 kHz to about 3 V at 10 kHz
DC Offset ............................................................... Magnetic remanence that follows abrupt changes in output current
level may cause small changes to DC current offset. It is good practice
to correct for offsets in DC measurements and techniques such as DC
reversal measurement will result in best accuracy.
Operated within 5730A Control Loop (all current ranges)
The current specification of the 52120A, when controlled by a single 5730A, applies to the parallel output of up to three
52120As connected as slaves.
Coverage factor k=2.58 (99 % confidence level)
Current Specification
Frequency
1-year, tcal
[1]
±5 °C ±(% of output + % of range)
5730A
% of output % of range
DC 0.015 0.010
10 Hz to 850 Hz 0.011 0.003
850 Hz to 6 kHz 0.052 0.005
6 kHz to 10 kHz See Operated Stand Alone current specification table in the 52120A Users Manual.
Notes:
1. tcal is the temperature at which calibration adjustment took place.
Maximum inductance for stability LCOMP OFF is 100 μH. Maximum inductance for stability LCOMP ON is 400 μH for 2 A and 20 A
ranges. 100 μH on the 120 A range.
With LCOMP ON, the output is limited to 7.2e3 A-Hz. For example, a 100 A output is limited to 72 Hz.
Coverage factor k=2.00 (95 % confidence level)
Current Specification
Frequency
1-year, tcal
[1]
±5 °C ±(% of output + % of range)
5730A
% of output % of range
DC 0.012 0.008
10 Hz to 850 Hz 0.009 0.002
850 Hz to 6 kHz 0.040 0.004
6 kHz to 10 kHz See Operated Stand Alone current specification table in the 52120A Users Manual.
Notes:
1. tcal is the temperature at which calibration adjustment took place.
Maximum inductance for stability LCOMP OFF is 100 μH. Maximum inductance for stability LCOMP ON is 400 μH for 2 A and 20 A
ranges. 100 μH on the 120 A range.
With LCOMP ON, the output is limited to 7.2e3 A-Hz. For example, a 100 A output is limited to 72 Hz.

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
