Fluke 5730A User Manual

Front-Panel Operation
Set up the Calibrator 4
4-47
Menu Description
A menu item that leads to a submenu with multiple selections has a black and amber title
bar on top followed by a list of the items in the submenu. The Instrument Setup menu is
shown in this example:
Instrument Setup
Remote Port
Uncertainty Information
Output Limits
Sourcing Hardware
To get to the submenus, touch anywhere in the menu shown.
Touchscreen Selections
When applicable, settings controlled by touchscreen selections are shown in this manner:
Remote Port
RS-232
Setup
Exit
Instrument
Settings
Stop Bits 1
Port Stall XON
Restore Factory Defaults
Parity None
Data Bits 8
EOL CRLF
Remote IF Terminal
EOF 012 000
Baud 9600
Setup Menu
hhp149.eps
Each of the touchscreen selections shown above change a parameter or reveal more
changeable parameters.

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
