Fluke 5730A User Manual

5730A
Operators Manual
7-16
Calibrator
HI
HI
HI
LO
LO
LO
OUTPUT
HI
LO
GND
GRD
752A Voltage Divider Standard
INPUT
REFERENCE
STANDARD
NULL
DETECTOR
732B Voltage
Reference Standard
732B DC STANDARD
AC PWR IN CAL CHARGE LOW BAT
10V 1.018V CHASSIS
GUARD1.018V COM10V COM
SERIAL NUMBER
External
Sense
OFF
External
Guard
OFF
Null Detector
NC
hhp029.eps
Figure 7-6. 220 V DC Range Calibration Connections

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
