– The delta cursor is labeled
D
and is used in both the spec-
trum and time waveform graphs. The delta cursor always
accompanies the main cursor. The delta cursor moves to the
second highest value. The cursor information box ( )
shows the difference between the main and delta cursors. The
value shown has the x-axis units. In the spectrum graph, the
information box shows also the values for the main and delta
cursors in orders.
– The harmonics cursors are labeled to a maximum of 6 on
the spectrum. The harmonics cursors accompany the main
cursor and are equidistant to the main cursor and to each
other. The cursor information box ( ) shows the difference
between the main cursor and the second harmonic. The value
shown has the x-axis units. In the spectrum graph, the inform-
ation box shows also the values for the main and delta cursors
in orders.
