Server mode deployment Example 1: FortiMail unit behind a firewall
FortiMail™ Secure Messaging Platform Version 4.0 Patch 1 Install Guide
Revision 2 143
http://docs.fortinet.com/ • Feedback
The FortiMail unit has also been configured with an access control rule that allows local
and remote email users to send email to unprotected domains if they first authenticate:
To deploy the FortiMail unit behind a NAT device such as a firewall or router, you must
complete the following:
• Configuring the firewall
• Configuring the email user accounts
• Configuring the MUAs
• Testing the installation
Configuring the firewall
With the FortiMail unit behind a FortiGate unit, you must configure policies to allow traffic:
• from the Internet to the FortiMail unit
• from the FortiMail unit to the Internet
To create the required policies, complete the following:
• Configuring the firewall address
• Configuring the service groups
• Configuring the virtual IPs
• Configuring the firewall policies
Configuring the firewall address
In order to create the outgoing firewall policy that governs the IP address of the FortiMail
unit, you must first define the IP address of the FortiMail unit by creating a firewall address
entry.
To add a firewall address for the FortiMail unit
1 Go to Firewall > Address > Address.
2 Select Create New.
3 Complete the following:
Sender Pattern *@example.com
Recipient Pattern *
Sender IP/Netmask 0.0.0.0/0
Reverse DNS
Pattern
*
Authentication
Status
authenticated
TLS < none >
Action RELAY
Note: This example assumes you have already completed the Quick Start Wizard and
configured records on the DNS server for each protected domain. For details, see “Quick
Start Wizard” on page 77 and “Configuring DNS records” on page 139.
Note: The following procedures use a FortiGate unit running FortiOS v3.0 MR7. If you are
using a different firewall appliance, consult the appliance’s documentation for completing
similar configurations.
