12 Chapter 1 DaqPRO
b. Press the Enter button to enter the setup menu:
→ In – 1 Voltage 0–10V
In – 2 Empty
In – 3 Empty
In – 4 Empty
RATE = Every sec
SAMPLES = 500
DISPLAY = numeric
c. Use the Forward
and Backward arrow buttons to select the sensor
in input 1 and then press the Enter button
. The arrow indicator will move to
the second input.
d. Repeat this procedure with all the sensors you plugged in.
e. After the fourth sensor has been selected, the screen will list the next 4 sensors:
→ In – 5 Empty
In – 6 Empty
In – 7 Empty
In – 8 Empty
RATE = Every sec
SAMPLES = 500
DISPLAY = numeric
You can press the Enter button in the last input if you want to go back to the first
input.
f. When you’ve finished selecting the sensors press the Escape button
. The
arrow indicator will point to the Rate command.
