Chapter 1 DaqPRO 13
4. Select Rate
a. Use the Forward
and Backward arrow buttons to select the
desired rate, then press the Enter button
.
In – 1 Current 0–24mA
In – 2 NTC 10K
In – 3 Empty
In – 4 Empty
→ RATE = Every 10 sec
SAMPLES = 500
DISPLAY = numeric
DaqPRO automatically switches to the next step in the setup process and the arrow
moves to the samples row.
5. Select Total Number of Samples
a. Use the Forward
and Backward arrow buttons to select the
number of samples, then press the Enter button
.
In – 1 Current 0-240 mA
In – 2 Thermocouple T
In – 3 Empty
In – 4 Empty
RATE = Every sec
→ SAMPLES = 10,000
DISPLAY = numeric
