Framery 2Q Huddle
4. Install the base plate of the display bracket to the left-hand side wall with 4x40 screws
(4 pcs).
The height of the base plate depends on its size.
Note: Make sure that the seal on the wall is in the middle of the base plate.
Note: Make sure that the base plate is vertically straight before tightening the
screws.
5. Install the wall bracket onto the base plate with M6x8 screws (2 pcs).
Note: Make sure that you check the straightness of the base plate.
Note: Make sure that the release mechanism cord is downwards.
Installation instructions
info@frameryacoustics.com
149
