Framery 2Q - Install the Front Center Frame

Framery 2Q Huddle
10.5 Install the front center frame
1. Install the guide pins (2 pcs).
2. Install the front center frame with M8x55 bolts (3 pcs) and M8 washers (3 pcs).
Note: Press the acoustic panel aside to reach the bolt holes. Make sure that
you return the acoustic panel to its original position.
88
Installation instructions
