Framery 2Q Huddle
3. Install one support beam on each side of the wall modules with flanged M8x50 bolts (4
pcs).
The support beams extend past the sides of the wall modules.
Warning: Support the walls continuously until the support beams are installed.
6.3.2 Install the front half of the roof to the wall modules
1. Install guide pins (4 pcs) to the installation holes at the top of the wall modules.
Note: Make sure that the guide pin is in the installation hole that is closer to
the wall felt.
2. Turn the combined roof modules onto the floor.
42
Installation instructions
